GB3DA/ER Voice Repeaters
Equipment Cabinet

From top to bottom:-
Behind the silver panel at the top are the GB3ER Cavities. Next is the GB3ER 70cm transceiver, then the two logic units, and then the GB3DA 2m transceiver. The tall grey cylinders are the GB3DA cavity set. At the bottom is the power supply, including lead acid battery backup system.

Previous     Next
Cabinet, July 1998
